A hexagonal Prism has one of its rectangular face parallel to Horizontal Plane. It's axis is perpendicular to the vertical Plane. The Prism is 35 mm above the ground. Draw the projection when the nearest end is 20 mm infront of the vertical plane. Each edge of hexagonal face is 20 mm and Axis of prism is 50 mm long.
-
