Lab Overview:

The Mitutoyo Metrology Lab is an advanced facility established with generous support of Rs.5,00,000/- from Mitutoyo South Asia Pvt. Ltd. to promote precision measurement and quality control education among Mechanical Engineering students. This lab provides hands-on experience with high-accuracy measuring instruments, empowering students to perform dimensional inspection, geometric tolerance analysis, and precision evaluation of manufactured components.

The lab plays a crucial role in bridging the gap between theoretical understanding and industrial practice in metrology. It supports students in their academic coursework, industrial projects, research work, and participation in national-level competitions. One notable utilization includes its role in Team Jatayu's ATV manufacturing, where accurate measurements were key to achieving optimal fit, tolerance, and performance.

The lab is fully equipped with air conditioning and LAN connectivity, offering a conducive and modern environment for precision learning.

Key Equipment in the Lab:

S.No.	Name of the Equipment	Use of Equipment	Image of Equipment
1	DIGIMATIC CALIPER                       RANGE: 0-300 MM RESO: 0.01 MM RANGE: 0-300 MM	Used for precise linear measurements.
2	DIGIMATIC LONG CALIPER RANGE: 0-600 MM RESO: 0.01 MM RANGE: 0-600 MM	For measuring larger components.
3	DIAL TEST INDICATOR RANGE: 0.2 MM GRAD: 0.002MM (HORIZONTAL TYPE)	Ideal for checking surface flatness and alignment.
4	CLAMP BOX FOR BEVEL PROTRACTOR	Supports angular measurement setups.
5	DIGIMATIC UNIVERSAL PROTRACTOR BLADE LENGTH:150 MM BLADE LENGTH:150 MM	Facilitates accurate angle measurements.
6	DIGITAL PROTACTOR -PRO 360 WITHOUT OUTPUT WITHOUT OUTPUT	A portable angle measuring device used without external output.
7	THICKNESS GAGE RANGE: 0.05-1 MM LEAVES: 28 LENGTH: 100 MM	For measuring small gaps and sheet thicknesses.
8	OUTSIDE MICROMETER RANGE: 0-25 MM GRAD: 0.001 MM RANGE: 0-25 MM	For external dimensional measurements with 0.001 mm accuracy.
9	OUTSIDE MICROMETER RANGE: 25-50 MM GRAD: 0.001 MM RANGE: 25-50 MM	For larger component measurement, also with 0.001 mm accuracy.
10	DIGIMATIC HEIGHT GAGE RANGE:0-1000 MM RESO:0.01 MM RANGE: 0-1000 MM	For height and step measurements on surface plates.
